RC Conversion Kit for Trumpeter 1/16 Sd.Kfz 251D
Inside connections
Gearbox machine gun firing
Torsion bars Torsion bars
Steering mechanism
Maching gun firing, with LED and swing motor Machine gun swing motor
Steering mechanism
Speaker Metal track pins with drill jig Metal track pins with drill jig


K24 - RC Conversion Kit for Trumpeter 1/16 Sd.Kfz 251D Half Track

Full Option - US$239
Without WCU (no machine gun firing and engine sound) - US$199

Status:    In Stock

- Metal torsion bars, adjustable and removable for easy maintenance and painting
- 180 size carbon brush motor. Metal gearbox with 8 ball bearing.
- Turning by differential gears and mechanical brake as real vehicle.
- ESC included
- Metal track pins. Drill jig for precision drilling of track pin holes.
- Metal steering wheel shafts and leaf string.
- Metal gear steering servo.
- Powered by 2 Cell 7.4V Lipo battery (Lipo battery NOT included and must be purchased separately)

- Optional WCU (weapon control unit):
- provide machine gun firing effects, with gun flash LED and machine gun swing motor.
- provide engine sound effects, with engine startup, idling and running sound. Engine sound changes according to speed.

Kit contains:
- Carbon brush motor and gearbox assemble, with differential gear, ESC, turning brake and metal gear steering servo
- Metal sprocket mounts
- Metal track pins with drill jig
- Metal torsion bars
- Adjustable and removable torsion bar mounting plates
- Metal steering wheel shafts, control bar and leaf spring
- Snap catch set for upper and lower hull
- Detail construction manual
- Optional WCU (weapon control unit): WCU V1.0, machine gun flash LED, swing motor, speaker

Following items are required but NOT included. You must purchase them separately:
- Trumpeter 1/16 Sd.Kfz 251D half track kit (Item no: 00942)
- RC transmitter and receiver (2CH or 3CH for WCU)
- 2 Cell 7.4V Lipo battery (Attention! Lipo battery can be dangerous if not use
  properly. Follow all safety precautions and use a dedicate Lipo battery charger)

RC Conversion Kit for Trumpeter 1/16 Sd.Kfz 251D Half Track User Manual
WCU (weapon control unit)  Manual V1.0

This conversion kit is designed for experienced model maker which may be difficult for beginners. Please read the manual to see if you have the skill and tools required.
